Ashok Leyland Stag 1212


৳ 1,875,000

The Ashok Leyland Stag 1212 is a 37+D (2×2) seater bus with ‘H’-series 4 cylinder 3.84L BS3 Diesel Engine with Turbocharger & Intercooler.

Category:

Engine ‘H’-series 4 cylinder 3.84L BS3 Diesel Engine with Turbocharger & Intercooler
Emission compliance BS3 with in-line fuel pump
Maximum Power 120 HP (88 kW) @ 2400 rpm
Maximum Torque 415 Nm @ 1400 rpm
Clutch 330 mm Hydraulic clutch actuation with booster
Transmission ZF 5 Speed forward Synchromesh gearbox
Rear Axle Fully floating single-speed hypoid gear
Front Axle Forged ‘I’-section Reverse Eliot type steerable
Frame Ladder type chassis with bolted cross member
Suspension Semi-elliptical multi-leaf with shock absorber at front & rear
Steering Integral power steering RHD
Brakes

Service Brake: Duel circuit full air ‘s’ cam brake

Parking Brake: Spring actuated at rear only

Electricals Battery: 12 volts 130 Ah | Alternator capacity: 65 Amps
Fuel tank 115 Liters
Frame Ladder type chassis with bolted cross member
Application City | Staff | School | Tourist
Variant STAG 1212
Wheel base (mm) 4900
Front overhang (mm) 1550
Rear overhang (mm) 2940
Overall length (mm) 9420
Overall width (mm) 2350
Turning Circle dia. (M) 18.3 M
Floor Height (mm) 900 (E+2)
GVW (kg.) 9,300
Tyre size 8.25 x 16 – 16 PR
Seating Layout 37+D (2×2)
