Eicher Terra 20H


৳ 3,440,000

Category:

Key Specifications

Power 183
GVW 25000 kg
Wheelbase 4000 mm
Engine 5883 cc
Fuel Tank 220 Ltr
Payload 14750 Kgs
Transmission Manual

Performance

Max Power 183
Displacement (cc) 5883 cc
Fuel Tank (Litres) 220 Ltr
Transmission Manual
Emission Norms BS-III
Gradeability (%) 27 %
Gearbox 6-Speed
Engine Cylinders 6
Max Speed (km/h) 78
Turning Radius (mm) 7900
Engine Cummins B5.9 BS3
Max Torque 685 Nm
Clutch Single Plate dry Push Type, 380 mm with Clutch Booster

Design & Build

GVW / GCW (Kgs) 25000 kg
Wheelbase (mm) 4000 mm
Payload (Kgs) 14750 Kgs
Tiltable Cabin Yes
Cabin Type Sleeper Cabin
Axle Configuration 6×4
Overall Width (mm) 2500
Ground Clearance (mm) 252
Rear Tyre 10.00 x 20 – 16PR
Overall Length (mm) 7590
Overall Height (mm) 3425
Kerb Weight (Kgs) 10250
Chassis Type Chassis with Cabin
Body Option Box body

Comfort

A/C No
Cruise Control No
Navigation System No
Driver Information Display No
Telematics No
Adjustable Driver Seat No
Tiltable Steering No
Arm-rest No
Seat Type Standard
Steering Hydraulic Power-assisted

Safety

Fog Lights No
Power Steering Yes
Rear Axle Heavy-duty fully floating banjo type
Front Axle Heavy-duty forged “I” beam reversed Elliot type
Front Suspension Semi-elliptical laminated leaf springs, Hydraulic double acting telescopic shock absorbers in front only
Rear Suspension Semi-elliptical laminated leaf springs, with bell crank mechanism in the rear
Brakes Air Brakes
ABS No
Parking Brakes Yes
Tubeless Tyres No
Seat Belts Yes
Hill Hold No

Others

Floor Type No
Electricals 24V
Body Material No
Canopy Length No
Water Tank Capacity (KL) No
Water Tank Type No
No. Of Valves No
Pump Type No
Bulker Type No
Bulker Discharge Pipe No
Bulker Air Inlet Pipe No
Bulker Equipments No
Bulker Electricals No
Floor Material No
Length {mm (ft.)} No
Side Board Material No
Width {mm (ft.)} No
Rear Board Material No
Height {mm (ft.)} No
External/Interior Surface No
No. Of Axles No
Refrigerating Unit No
Axle Types No
Temperature Range No
Chassis No
Size (Cu. M) 14
Landing Gear No
