Basic Specification
| Vehicle Data | |
| Model | HFC1120P71K |
| Drive Mode | RHD 4X2 |
| Emission Standard | EURO – ll |
| Cabin | Single Sleeper Cab (Tilt Type) |
| Transmission | |
| Transmission Model | 6DS60T-D |
| Gears | 6 forward 1 reverse |
| Dimensions | |
| Overall Size (mm) (L*W*H) | 8230*2442*2540 |
| Cargo Dimension (mm) (L*W*H) inside | 6200*2240*550 |
| Cargo Dimension (mm) (L*W*H) Outside | 6400*2442*640 |
| Front Over Hang (mm) | 1180 |
| Rear Over Hang (mm) | 2350 |
| Tread (F/R)(mm) | 1700/1800 |
| Wheelbase (mm) | 4700 |
| Engine | |
| Engine Model | B170 33 |
| Type | Lin Line,6 Cylinders, Turbocharged & Intercooler Diesel Engine |
| Displacement (CC) | 5900 |
| Compression Ratio | 17.05 |
| Max. Power (hp/rpm) | 170hp (125kw)/ 2500rpm |
| Max Torque (N.m @ Rpm) | 560 nm / 1300 rpm |
| Brakes, Wheels and Tyres | |
| Break System | Air Brake |
| Steering Type | Power Steering |
| Tyre Size | 255/70R22.5=6 pcs |
| Number of tyre | 6+1 |
| Weights | |
| Curb Weight (kg) | 4745 |
| Max Load Capacity (Kg) | 4755 |
| Gross Vehicle Weight (Kg) | 9500 |
| Seating Capacity | 2+1 |
| Features | |
| Fuel tank Capacity | 210 |
| Ground Clearence (mm) | 200 |
| Turning radius (m) | 10.5 |
| Side over hang (mm) | N/A |
| Air Conditioner | Yes |
| Power Steering | Yes |
| Wind Deflector | Yes |
| Side Bumper | Yes |
| Rear Bumper | Yes |
| Seat belt warning | Yes |
| Digital Radio and mp3 | Yes |
| CD Player | N/A |
| Remarks | X- Not Available, O-Optional, Standard Equipment |
