Engine | |
Engine Type | 4-stroke, Single – Cylinder, air-cooled diesel engine |
Displacement | 436 cc |
Maximum Power (KW) | 7.5BHP @3600 rpm |
Maximum Torque (NM) | 18 Nm @ 2000-2400 rpm |
Clutch Type | Multi-Plate Wet Clutch |
Transmission | Constant Mesh, 4 Forward + 1 Reverse |
Suspension | |
Front | Anti dive leading link with helical spring & hydraulic shock absorber |
Rear | Independent swinging arm and hydraulic shock absorber with rubber spring. |
Brakes | Dual circuit International Expending tyre hydraulic Breaks |
Parking Brakes | Mechanical on Rear Wheel |
Wheels & Tyres | 4.50″ x 10″, 8PR |
Max Speed | 53km/hr |
Electrical System | |
System Voltage | 12v |
Battery | 12v, 50 AH |
Starting System | self Ignition key type |
Wiper | single speed monoblade |
Starting Motor | 1 KW |
Fuel Tank Capacity (Litres) | 10.5 |
Vehicle Dimensions (mm) | |
Wheel Base (mm) | 2005 |
Wheel Track (mm) | 1250 |
Turning Radius (mm) | 3500 |
Min Ground Clearance (mm) | 175 |
Overall Width (mm) | 1452 |
Overall Height (mm) | 1866 |
Overall Length (mm) | 2978 |
Weight | |
Max. GVW (kg) | 780 |
Kerb Weight (kg) | 460 |
Seating Capacity | Driver + 3 Passenger / Driver + 5 Passenger |
