Dimensions |
|
|
Overall Length x Width x Height |
4785 mm x 1815 mm x 1800 mm (Height- 1,805 mm with roof wall) |
|
Wheelbase |
2,800 mm |
|
Track |
1,520 mm |
|
Interior Length |
2,585 mm |
|
Interior  Width |
1,420 mm |
|
Interior  Height |
920 mm |
|
Cargo Room Length |
1,575 mm |
|
Cargo Room Width |
1,370 mm |
|
Cargo Room Height |
885 mm |
|
Min. Ground Clearance |
218 mm |
|
Curb Weight |
2,015 kg |
|
Gross Vehicle Weight (GVW) |
2,710 kg |
|
PayLoad |
695 kg |
|
Seating Capacity |
7 persons |
|
Performance |
|
|
Max. Speed |
166 km/h |
|
Climbing Ability |
1 tan θ |
|
Min. Turning Radius |
5.6 m |
|
Approach Angle |
30° |
|
Departure Angle |
24.6° |
|
Engine |
|
|
Type |
4D56 Direct Injection Diesel Common Rail Intercooled Turbo Charge |
|
Total Displacement |
2477 cc |
|
Bore x Stroke |
91.1 x 95.0 mm |
|
Compression Ratio |
17 |
|
Max. Output (EEC net) |
100/4000 kW/rpm |
|
Max. Torque (EEC net) |
324 /2000 N-m/rpm |
|
Electrical System |
|
|
Battery |
80D26 |
|
Alternator |
90 A |
|
Fuel System |
|
|
Fuel Supply Equipment |
Electronic Control Injection (Common Rail) |
|
Fuel type |
Diesel |
|
Fuel Tank Capacity |
68 L |
|
Transmission |
|
|
Type |
5A/T (V5AWF) |
|
Steering |
|
|
Type |
Rack & Pinion with Power Steering |
|
Suspensions |
|
|
Front |
Independent Double Wishbone, Coil Spring with Stabilizer Bar |
|
Rear |
3-Link Coil Springs with Stabilizer Bar |
|
Brakes |
|
|
System |
Vacuum Brake Booster |
|
Front |
Ventilated Disc Brake (1POT Diameter 294 mm) |
|
Rear |
Drum Brake |
|
Tires |
|
|
Wheels |
16 x 7.0 j Alloy Wheels |
|
Size |
265/70R16 |
