Engine
| No. Of Cylinder |
3 |
| HP Category |
34 HP |
| Capacity CC |
2146 CC |
| Engine Rated RPM |
2200 |
| Cooling |
Water Cooled |
| Air Filter |
Oil Bath Type |
| PTO HP |
31.4 |
Transmission
| Type |
Constant Mesh with Center Shift |
| Clutch |
Single |
| Gear Box |
8 Forward + 2 Reverse |
| Battery |
12 v 75 Ah |
| Alternator |
2 V 35 A |
| Forward Speed |
29.3 kmph |
| Reverse Speed |
10.8 kmph |
Brakes
| Brakes |
Multi Plate Disc Brake |
Steering
| Type |
Mechanical |
| Steering Column |
Single Drop Arm |
Power Take Off
Fuel Tank
Dimensions And Weight Of Tractor
| Total Weight |
1805 KG |
| Wheel Base |
2010 MM |
| Overall Length |
3260 MM |
| Overall Width |
1700 MM |
| Ground Clearance |
375 MM |
| Turning Radius With Brakes |
3150 MM |
Hydraulics
| Lifting Capacity |
1500 kg |
| 3 point Linkage |
Automatic Depth & Draft Control |
Wheels And Tyres
| Wheel drive |
2 WD |
| Front |
6.00 x 16 |
| Rear |
12.4 x 28 |
Other Information
| Accessories |
Tools, Bumpher , Ballast Weight, Top Link , Canopy , Drawbar |
| Additional Features |
High torque backup, Adjustable Seat , High fuel efficiency |
| Warranty |
5000 hours/ 5 Year |
