Key Specifications

Power 136
GVW 16200 kg
Wheelbase 4225 mm
Engine 5883 cc
Fuel Tank 350 Ltr
Payload 11250 Kgs
Transmission Manual


Max Power 136
Displacement (cc) 5883 cc
Fuel Tank (Litres) 350 Ltr
Transmission Manual
Emission Norms BS-III
Gradeability (%) 22 %
Gearbox 6-Speed
Turning Radius (mm) 8350
Engine Cylinders 6
Engine Tata CuMmins 6BT BS-III
Max Torque 490Nm
Clutch 352 mm dia., Single Plate dry friction type, with ceramic lining
Max Speed (km/h) 102

Design & Build

GVW / GCW (Kgs) 16200 kg
Wheelbase (mm) 4225 mm
Payload (Kgs) 11250 Kgs
Axle Configuration 4×2
Cabin Type Sleeper Cabin
Chassis Type Chasis with Cabin
Front Tyre 10 x 20 – 16 PR
Rear Tyre 10 R 20-16 PR
Overall Length (mm) 7710
Overall Width (mm) 4225
Overall Height (mm) 2704
Kerb Weight (Kgs) 4950
Ground Clearance (mm) 260
Body Option Customizable
Tiltable Cabin No


A/C No
Cruise Control No
Navigation System No
Telematics No
Adjustable Driver Seat No
Tiltable Steering No
Arm-rest No
Seat Type Standard
Steering Power Steering
Driver Information Display Yes


Hill Hold No
Fog Lights No
Power Steering Yes
Rear Suspension Semi elliptical Leafs PR ings suspension
Front Suspension Semi Elliptical Leaf S PR ing
Front Axle Extra heavy-duty Forged “I” beam reverse Elliot type Axle,
Rear Axle Single-speed, Hypoid gears, Extra heavy-duty Axle
Brakes Air Brakes
Parking Brakes Yes
Tubeless Tyres No
Seat Belts Yes


Floor Type No
Length {mm (ft.)} 5486(18)
Body Material No
Chassis Ladder-type heavy-duty frame with riveted and bolted cross members
Canopy Length No
Water Tank Capacity (KL) No
Water Tank Type No
No. Of Valves No
Pump Type No
Bulker Type No
Bulker Discharge Pipe No
Bulker Air Inlet Pipe No
Bulker Equipments No
Bulker Electricals No
Floor Material No
Side Board Material No
Size (Cu. M) No
Rear Board Material No
Width {mm (ft.)} No
External/Interior Surface No
Height {mm (ft.)} No
Refrigerating Unit No
No. Of Axles No
Temperature Range No
Axle Types No
Body Brakes Air Brakes
Landing Gear No
Electricals No
