QUICK FACTS & INFORMATION |
|
| Body Type | MUV |
| Fuel Type | Diesel |
| ARAI Certified Mileage | 35 kmpl |
| Top Speed (KMPH) | 55 |
| Official Tagline | Public Transport Ka Ek Naya Avatar |
ENGINE & TRANSMISSION |
|
| Engine Displacement | 611 cc |
| Maximum Power | 10.84 Bhp @ 3000 rpm |
| Maximum Torque | 31 Nm @ 1600 rpm |
| Engine Description | 4 Stroke, Naturally Aspirated, Direct Injection , Water-Cooled Diesel Engine |
| No. of Cylinders | 1 |
| Clutch Type | Single Plate, Dry Friction Diaphragm Type, TA59 With Synchromesh (4 Forward Gears), Constant Mesh (Reverse Gear) |
| Front Axle | Independent Stub Axles |
| Rear Axle | Transaxle With CV Shafts |
| Emission Standard | BS III |
PERFORMANCE & MILEAGE |
|
| Mileage (City) | 28 kmpl (approx.) |
| Mileage (Highway) | 32 kmpl (approx.) |
DIMENSIONS & WEIGHT |
|
| Overall Length | 2960 mm |
| Overall Width | 1512 mm |
| Overall Height | 1800 mm |
| Wheelbase | 1650 mm |
| Ground Clearance | 160 mm |
| Kerb Weight | 685 kg |
| Gross Vehicle Weight | 1110 kg |
| Turning Radius | 3.50 metres |
| Front Track | 1250 mm |
| Rear Track | 1310 mm |
CAPACITY |
|
| Seating Capacity | 4 (2 + 2) |
| Number of Seating Rows | 2 Rows |
| Number of Doors | 4 Doors |
| Fuel Tank Capacity | 10 litres |
BRAKES & SUSPENSION |
|
| Front Brakes | Hydraulically Activated Drum Brakes |
| Rear Brakes | Hydraulically Activated Drum Brakes |
| Front Suspension | Independent MacPherson Strut, Hydraulic Double Acting Shock Absorber |
| Rear Suspension | Coil Spring With Semi Trailing Arm, Hydraulic Double Acting Shock Absorber |
WHEELS & TYRES |
|
| Tyre Size | 145/80 R12 X 6 PR Radial |
COMFORT & CONVENIENCE |
|
| Power Sockets | |
| Air Conditioner | |
| Front Bucket Seats | Yes (Driver & Co-Driver) |
EXTERIOR FEATURES |
|
| Tinted Glass | |
| Body | All Steel Body With Double Sheet Steel Doors |
INTERIOR FEATURES |
|
| Glove Box | Yes (Lockable) |
| Sunvisor with Ticket Holder | Yes (At Driver Side) |
ACTIVE & PASSIVE SAFETY FEATURES |
|
| Rear Seat Belts | |
| Front Seat Belts | |
INFOTAINMENT |
|
| Music System | |
SEATS & UPHOLSTERY |
|
| Folding Rear Seats | |
| Fabric Upholstry | |
| Driver Seat Adjustment | Yes (Manually Adjustable Driver & Co-Driver Seat) |
OTHER SPECIFICATIONS |
|
| Steering | Wheel Steering, Mechanical Rack & Pinion Type, 350 mm Diameter |
