Hiace 12 Diesel
| ENGINE | ||
| Engine Model | : | 5L-E (Diesel) |
| Engine Type | : | 4 Cylinder L-Type |
| Valve Mechanism | : | 8-Valve, OHC |
| Piston Displacement | : | 2986 CC. |
| Max. Output (kw / rpm) | : | 68 / 4000 |
| Max. Torque (Nm / rpm) | : | 197 / 2400 |
| Fuel system | : | Distributor Type |
| CHASSIS | ||
| Transmission Type | : | 5-Speed Manual |
| Front Suspension | : | Double Wishbone |
| Rear Suspension | : | Leaf Spring |
| Fuel Tank Capacity | : | 70 |
| Min Turning Radius (m) | : | 5.0 |
| Tires | : | 195R 15C T/L |
| DIMENSIONS & WEIGHT | ||
| Overall length (mm.) | : | 4695 |
| Overall width (mm.) | : | 1695 |
| Overall height (mm.) | : | 1980 |
| Ground Clearance (mm.) | : | 185 |
| Gross vehicle weight (kg.) | : | 3000 |
| Seating Capacity | : | 12 Persons (Including Driver) |
Hiace 12 Petrol
| ENGINE | ||
| Engine Model | : | 2TR-FE (Gasoline) |
| Engine Type | : | 4 Cylinder L-Type |
| Valve Mechanism | : | 16-Valve, DOHC, VVT-i |
| Piston Displacement | : | 2694 CC. |
| Max. Output (kw / rpm) | : | 111 / 4800 |
| Max. Torque (Nm / rpm) | : | 241 / 3800 |
| Fuel system | : | Electronic Fuel Injection (EFI) |
| CHASSIS | ||
| Transmission Type | : | 5-Speed Manual |
| Front Suspension | : | Double Wishbone |
| Rear Suspension | : | Leaf Spring |
| Fuel Tank Capacity | : | 70 |
| Min Turning Radius (m) | : | 5.0 |
| Tires | : | 195R 15C 8PR T/L |
| DIMENSIONS & WEIGHT | ||
| Overall length (mm.) | : | 4695 |
| Overall width (mm.) | : | 1695 |
| Overall height (mm.) | : | 1980 |
| Ground Clearance (mm.) | : | 185 |
| Gross vehicle weight (kg.) | : | 2950 |
| Seating Capacity | : | 12 Persons (Including Driver) |
Hiace 15 Diesel
| ENGINE | ||
| Engine Model | : | 5L-E (Diesel) |
| Engine Type | : | 4 Cylinder L-Type |
| Valve Mechanism | : | 8-Valve, OHC |
| Piston Displacement | : | 2986 CC. |
| Max. Output (kw / rpm) | : | 68 / 4000 |
| Max. Torque (Nm / rpm) | : | 197 / 2400 |
| Fuel system | : | Distributor Type |
| CHASSIS | ||
| Transmission Type | : | 5-Speed Manual |
| Front Suspension | : | Double Wishbone |
| Rear Suspension | : | Leaf Spring |
| Fuel Tank Capacity | : | 70 |
| Min Turning Radius (m) | : | 5.0 |
| Tires | : | 195R 15C T/L |
| DIMENSIONS & WEIGHT | ||
| Overall length (mm.) | : | 4695 |
| Overall width (mm.) | : | 1695 |
| Overall height (mm.) | : | 1980 |
| Ground Clearance (mm.) | : | 185 |
| Gross vehicle weight (kg.) | : | 3000 |
| Seating Capacity | : | 15 Persons (Including Driver) |
Hiace 15 Petrol
| ENGINE | ||
| Engine Model | : | 2TR-FE (Gasoline) |
| Engine Type | : | 4 Cylinder L-Type |
| Valve Mechanism | : | 16-Valve, DOHC, VVT-i |
| Piston Displacement | : | 2694 CC. |
| Max. Output (kw / rpm) | : | 111 / 4800 |
| Max. Torque (Nm / rpm) | : | 241 / 3800 |
| Fuel system | : | Electronic Fuel Injection (EFI) |
| CHASSIS | ||
| Transmission Type | : | 5-Speed Manual |
| Front Suspension | : | Double Wishbone |
| Rear Suspension | : | Leaf Spring |
| Fuel Tank Capacity | : | 70 |
| Min Turning Radius (m) | : | 5.0 |
| Tires | : | 195R 15C 8PR T/L |
| DIMENSIONS & WEIGHT | ||
| Overall length (mm.) | : | 4695 |
| Overall width (mm.) | : | 1695 |
| Overall height (mm.) | : | 1980 |
| Ground Clearance (mm.) | : | 185 |
| Gross vehicle weight (kg.) | : | 2950 |
| Seating Capacity | : | 15Persons (Including Driver) |
